RK3588 Android smart motherboard adopts Rockchip RK3588 eight-core 64-bit large and small core architecture, four large cores Cortex-A76+ four small cores Cortex-A55, supports Google Android12 system, and supports the decoding of mainstream audio and video formats and pictures. Supporting 4K, H.264 hard decoding, multiple video outputs and inputs, the embedded 3DGPU makes RK3588 fully compatible with OpenGL ES 1.1/2.0/3.1/3.2, OpenCL 1.1, 1.2, 2.0 and Vulkan 1.1, 1.2. The special 2D hardware engine will maximize display performance and provide very smooth operation. Built-in 6TOPS computing power, triple-core architecture, supports int4/int8/int16/FP16/BF16/TF32 mixed operation performance, faster speed, interface Richer. Supports single and double 6/8-bit LVDS display output, and supports MIPI display output. Supports HDMI-8K output, supports EDP output, supports VBYONE 4K output, and supports 4K video playback. It supports 24GWH+BTWIH6, infrared remote control, gravity sensor, TYPE-C, IO port expansion and other functions. It has rich interfaces and is widely used in advertising machines, interactive all-in-one machines, security, industrial control and other intelligent control fields. Due to its hardware platform and Android intelligent characteristics, it can be used on the smart terminal motherboard when human-computer interaction or network device interaction is required.

Size: 170*120mm, up to 11mm, suitable for smart industrial control terminal equipment

Display interface: The board supports a variety of display output interfaces such as LVDS (6/8 bit), HDMI, EDP, MIPI, and V-BY-ONE

Rich expansion interfaces: 1 TYPE-C OTG, 6 USB2.0, 2 USB3.0 interfaces, 4 TTL serial ports (optional RS232*4/485*1), 4 GPIO interfaces, 1 I2C Interfaces, etc., can meet the requirements of various peripherals on the market

Multiple network interfaces: Gigabit Ethernet, WIFI2.4G (WiFi5/WiFi6 optional), 4G/5G network, Bluetooth

High definition: supports 4K hard decoding playback, supports horizontal and vertical screen playback, video split screen, rolling subtitles, scheduled power on and off, USB data import and other functions

Supports deep learning, posture analysis, and other AI application scenarios
